XL-650 Power Sports Sound Bar
- 6 Speaker 250 watt Amplified Bluetooth Powersports Soundbar
- IPX6 Rated
- 2 x 3.5" Square Poly Cone Woofers
- 2 x 3” Full Range Marine Grade Poly Cone Speakers
- 2 x 1” SD Mylar Tweeters
- Heavy Duty Extruded Aluminum Water Tight Housing
- LED back-lit Control Panel
- LED Visual Notifications
- Audible Power On/Off Notifications
- Built In DSP Processor
- Bluetooth and Wired RCA Inputs
- 2 Volt RCA Line Output
- Auto Turn On/Off Circuit
- Waterproof Wire Loom Connectors
- Universal L-Bracket or Stud Bolt-In Mounting System Included
- Universal Top or Bottom Mount Clamp Style Brackets (Sold Separately XL-SBCLAMP2, XL-SBTCLAMP, XL-SBSCLAMP)
- Optional Wireless Remote Control (Sold Separately XL-SBCONRF coming soon)
Read more
XL-650 6 SPEAKER AMPLIFIED POWERSPORTS SOUNDBAR
The XL Series Soundbars were developed for the growing power sports market including UTV and Marine applications where electronics must withstand harsh environments and are perfect for the off-road world. From UTV's to Jeeps, sand rails, dune buggies, boats and Rv's the XL Series Soundbar is a great way to enjoy your favorite music when you are on the trails bashing in the mud or sand, through the creeks and across the lake or even down the road letting the wind blow in your hair!
The XL Series Soundbar circuit board has been conformal coated with a layer of transparent material that protects the parts against moisture, dust and temperature extremes.
The NEW VERSION 2 XL Series Soundbars are available in in three different models; XL-1250 12 speaker 500W system, XL-850 8 speaker 300W system, and the newest size XL-650 6 speaker 250W system. The Version 2 series soundbars are the evolution of soundbar technology with advancements made in power and performance delivering the fullest sound possible in a self contained system for use in the hard off-road environment. Feel the bass as all of the new XL Series Soundbars are equipped with 3.5" marine grade poly cone subwoofers the only of its kind! Connecting additional equipment is simple with our newly redesigned full range 3V max RCA AUX OUTPUT you can now send signal directly to additional amplifiers to run subwoofers and pod speakers to give you even more sound when out on the trails. Installation is a 3 wire Power and Ground with a switched 12V input allowing your soundbar to be turned on and off by ignition or a rocker switch and the XL Series Soundbar comes equipped with built in Bluetooth as well as a RCA input for incorporating it into your existing source unit.
Soundbars mount just like a light bar, so if you can mount a light bar you can mount a sound bar! PowerBass offers (Sold Separately) heavy duty aluminum mounting clamps as well as thin square and round mounting brackets making this easy to install, look great, and sounds even better!
Specifications
- Peak Power: 1000 watts
- Power Supply: Unregulated PWM
- Inputs: Bluetooth/3.5 mm Wired
- Channels (mono): 2
- 2-ohm Power: 250 watts x 2
- Input Sensitivity: 0.25 V - 3.0 V
- S/N Ratio: >85 dB
- Output Power (14.4 V) @ 2 ohm: 250 watts x 2
- Frequency Response: 50 Hz - 22 kHz
Downloads
XL-650 Power Sports Sound Bar
